Security mesh screen It also can be named anti-theft screen, bulletproof screen, crim-safe security screen. It's woven by high quality stainless steel wire and with coated surface, so it has the high performance of high strength,simple and powerful, resisting shear and anti-shock to reach the features of bulletproof, anti-theft, ventilate, light transmitting, artistic and safe. It's widely used government department, luxury villas and commercial buildings.
Our Testing Standards
Diagonal Deviation, strict controls of +/- 5mm
Fine Grinding - The Surface Treatment Of 0.03mm
Double Plain Weave High Hardness To Bulletproof
Precipitation Of Metal Cons ,Non Magnetic
Steel Wire After Micron Grade Precision Machining
Approval Astrilian:
1. Knife Shear Test,
2. Fire Test,
3. Jammy Test,
4. The Probe Test
5. The 1000hours Salt Spry Test
Material
Stainless steel 316 grade has 10% to 14% nickle, which has very good resistance to corrosion. Using as window or door screens, we need a better material to keep for many years. So SS316 is the first choice.
Maishi do honest business, and we use real 316 stainless steel material.
Mesh Size x Wire Dia:
10mesh x 0.8mm, 10mesh x 0.9mm
11mesh x 0.8mm, 11mesh x 0.9mm, 12mesh x 0.7mm
14mesh x 0.5mm, 14mesh x 0.55mm, 14mesh x 0.6mm
Avaliable Screen Size
Width: 750mm, 900mm, 1000mm, 1200mm, 1500mm
Length: 2000mm, 2400mm, 3000mm
Coating Color
Black/Gray/White epoxy coated etc
Specification:
Stainless Steel Security Window Screen:
product specifications:| Item | Security Mesh | Safety Mesh/Pet Mesh | | Material | 304 and 316 stainless steel / galvanized | 304 stainless steel | | Wire Diameter | 1/.039 | 0.9/.035 | 0.8/.031 | 0.7/.028 | 0.6/.024 | 0.55/.022 | 0.5/.02 | | Before Coating(mm/inch) | | Mesh (per inch) | 10×10 | 11×11 | 11×11 | 12×12 | 14×14 | 14×14 | 14×14 | | Standard Colors | matt black, shinning bright, matt white, matt grey | | Standard Widths | 0.914m/3ft, 1.22m/4ft, 1.52m/4.99ft | | Standard Lengths | 31.2 meter or 102 feet per roll, customized length as request | | Weaving Method | plain woven | | Package | preferably flat sheet | flat sheet or roll | | Note | special specifications available upon request with minimum order quantity |
|
Material type: Stainless steel 304,304l,316,316l,
Weave type: plain weave style
Common specification: 11 mesh * 0.8mm wire, 11 mesh* 0.9mm wire,10 mesh * 0.9mm wire, 12mesh* 0.7mm wire,14 mesh* 0.6mm wire, 14 mesh * 0.7mm wire
Standard size: 750mm×2000mm 900mm×2000mm 1200mm×2000mm 750mm×2400mm 900mm×2400mm 1200mm×2400mm,1300mmx2600mm, 1500mmx2400mm.
Color: black,white, gray, dark gray,
